Salford BBI ENDURANCE MECHANICAL spreader

Call for Price
Overview
Salford BBI ENDURANCE MECHANICAL spreader BBI ENDURANCE MECHANICAL spreader

BBI Endurance is the industry leader in cost-in-use, the ultimate measure of efficiency in the field. Also available in a traditional, mechanical version powered by ground-wheel-drive. Unrivaled power, performance, and precision in targeted delivery of organic nutrients. Spread litter, manure, shavings, beet lime, and much more.

Endurance is the definition of excellence among litter spreaders on the market today, the standard-bearer for more than a decade. Built with Salford’s spinner system, Endurance achieves the same level of precision with heavier, wetter organic material normally achieved with the dry artificial stuff.

When we designed Endurance, we had chicken litter in mind, but the uses quickly spread to meet the needs of farmers around North America and the world. Now, our customers use Endurance for manure, shavings, lime, humalfa, sand organics, wood chips, mulch, humate, compost - pretty much any flowable material.

Endurance is an option-rich line, available in pull-type and truck-mount versions. We have multiple hopper designs ranging from 14–18 feet to match any possible need in the field. Our walking beam suspension can handle just about any terrain.

You can count on Endurance to help you achieve drastic reductions in material and fuel waste, while increasing your yield.

Specifications
Model
BBI ENDURANCE MECHANICAL spreader
Category Name
Agriculture
Year
2022
Sale Type
New
Manufacturer
Salford
features

FEATURES (MECHANICAL)

  • PTO Driven spreader with enclosed hydraulics

    • 540 or 1000 rpm PTO options

    • Heavy duty PTO shielding

  • Conveyor Drive

    • Specially designed 50:1 gear case with 2 inch output shaft to handle maximum torque

    • Gear case features 2 oil seals on each end to contain oil and prevent contamination

    • The split case housing does not require any shims

  • Conveyor

    • 34 inch wide conveyor

    • 88K Heavy duty, self-cleaning, pintle chain, with wide flat bars on every fourth link

  • Spinners

    • 24” spinner discs with 4 adjustable fins for the most accurate patterns

    • Angled flow divider for even distribution of material onto the discs

    • Spinner motors may be mechanically driven or plug to tractor hydraulic drive is optional.

    • Spinner motors are protected by a multi-seal system to prevent contamination

    • Spinner motors are protected by frame mounted shielding to prevent damage while in operation

technical specs.
ENDURANCE, Mechanical Drive
14 foot, 16 foot, 18 foot Hopper sizes
Hopper Material Standard: 10 Gauge Carbon Steel with Electrostatic Paint
Optional: 7 Gauge Carbon Steel Optional
Hopper Floor Standard: Steel
Optional: Poly
Hopper Capacity
Struck cubic feet
14 foot long hopper 16 foot long hopper 18 foot long hopper
Low profile hopper
(16 cu/ft, stuck per linear foot of hopper)
210 cu/ft / 5.25 240 cu/ft / 6 tons 270 cu/ft / 6.75 tons
Standard hopper
(20 cu/ft, stuck per linear foot of hopper)
266 cu/ft / 6.65 tons 304 cu/ft / 7.6 tons 342 cu/ft / 8.55 tons
High profile hopper
(23.5 cu/ft, stuck per linear foot of hopper)
322 cu/ft / 8.05 tons 368 cu/ft / 9.2 tons 414 cu/ft / 10.35 tons





Endurance Mechanical Drive Spreaders Hopper Type
Suspension Type Wheel Hub Tire Size Low Profile (Inches) Standard Profile (Inches) High Profile (Inches)
7000 lb Torsion-Flex" Tandem Axle" Standard
Equipment
6 Bolt 12.5 73.5 79.5 85.5
7000 lb Torsion-Flex" Tandem Axle" Optional 6 Bolt 14 76 82 88
9 Ton Heavy Duty Tandem Axle Suspension Optional 8 Bolt 16.5 81.5 87.5 93.5
9 Ton Heavy Duty Tandem Axle Suspension Optional 8 Bolt 500 81.5 87.5 93.5
9 Ton Heavy Duty Tandem Axle Suspension Optional 8 Bolt 21.5 83.5 89.5 95.5
10 Ton Walking Beam Optional 8 Bolt 16.5 83.5 89.5 95.5
10 Ton Walking Beam Optional 8 Bolt 500 83.5 89.5 95.5
10 Ton Walking Beam Optional 8 Bolt 21.5 85.5 91.5 97.5
14 Ton Walking Beam Optional 10 Bolt 21.5 85.5 91.5 97.5
14 Ton Walking Beam Optional 10 Bolt 550 88 94 100
14 Ton Walking Beam Optional 10 Bolt 700 88 94 100
